The DC06PRO has made significant advancements in the utilization of the ES9219C DAC chips thanks to thorough research, development, rigorous testing, and attentive listening sessions. Despite utilizing more expensive components, we have managed to maintain an exceptionally affordable price without making any compromises. Through the implementation of dual DAC chips, we have achieved a remarkable increase in power output relative to its compact size, while simultaneously minimizing the noise floor. The power consumption of the new generation ESS DAC has an excellent ratio to the power output. And the sound quality remains uncompromised, providing a rich and authentic audio experience that can be enjoyed on a daily basis.
In an exhilarating improvement, the DC06PRO incorporates advanced technology to create a separate power supply for the AMP section. This includes a synchronous DC-DC converter, a low noise charge pump chip, and an LDO. These implementations enable the AMP section to operate at its maximum capacity without any interference from the digital section. This enhances the dynamics, bass impact, and overall transparency of the sound.
The DC06PRO utilizes our in-house developed FPHA algorithm. Achieving an impressively low jitter is made possible through the utilization of the NDK femtosecond oscillator, resulting in minimal distortion and a notable enhancement in the quality of the musical sound.
The DC06PRO has hardware for rendering of MQA. For the process, software unfolds 2 times and the on-board hardware of the DAC unfolds a further 9 times. iBasso software is certified, which means you can plug and play to decode and enjoy your MQA files to their full potential.
High-grade aluminum alloy is used for the CNC milling of the DC06PRO case. An open volume control feature implements a number of complex steps during CNC. The results are both extremely functional and visually appealing. The overall result of the tempered hardened glass panels is both aesthetic and quality enhancing in combination with the precise CNC case machining.
The iBasso UAC App has been fully upgraded to work with the DC06PRO, which provides:
-100 Steps of Hardware Volume
-2 Options for Digital Filters
-20 Step L/R Balance
-On/Off Power Saver
The DC06PRO utilizes a USB-C input and can be used with a number of cable types. A USB-A to USB-C cable converter is also provided allowing for use with most Android devices. A Lightning cable can also be used with the DC06PRO.
DAC Chipset
Dual ES9219C QUAD DAC+ Chips
PCM
up to 32bit/384kHz
DSD
Native DSD64, DSD128, DSD256
MQA
16X
Weight
20g
THD +N
0.00035% (600Ω load) 0.0005% (32Ω load) / 0.00056% (600Ω load) 0.0007% (32Ω load)
Output Voltage
3.2Vrms (32Ω load) 4Vrms (300Ω load) / 2Vrms (32Ω load)
S/N
123dBA / 120dBA
Frequency Response
20Hz~40kHz -0.5dB / 20Hz~40kHz -0.5dB
Output Impedance
<0.5Ω / <0.3Ω
